VTX Foxeer Reaper Extreme 5.8G 3W 72CH
VTX Foxeer Reaper Extreme 5.8G 3W 72CH is a high-performance video transmitter designed for FPV drones. With an output power of 3W, this VTX delivers an exceptionally strong and clear video signal, making it ideal for long-range, high-interference environments. It supports 72 channels, which ensures wide compatibility and flexibility in channel selection.
Function:
- 3W high power
- Built-in microphone
- CNC shell for heat dissipation
- Great filter circuit, strong anti-interference ability
Specifications:
Name: Reaper Extreme 3W
Input voltage: 9~36V
Output voltage: 5V
Channels: 72CH
Power: 25mW/200mW/500mW/1.5W/3W, red light flashes 1/2/3/4/5 times accordingly
Pit: Double click to enter
Fan: Yes
Weight: 15.2g
Size: 38*29.2*11.5mm
Consumption: 1.4A/10V
- Unlock frequencies and power levels
Long press the “KEY” button until the red LED (PWR) is steady on, turn off and then on again, and release the button to unlock all frequencies and power levels, flashing red LED means unlocked status, steady red LED means locked status.
- Turn PIT mode on/off
Double click the "KEY" button to turn on/off PIT mode. Red LED (PWR) off means PIT mode is on; A lit red LED (PWR) means PIT mode is off. In PIT mode, the VTx provides extremely low power.
- Note:
If the tramp cable is connected, the button will not work, the frequency and power cannot be set, the controller will take over.
BetaFlight can receive a maximum of 64 channels, so the O-bands are removed by default.
The package includes:
1x VTX Reaper Extreme 3W
1x silicone cable
