    Code: HP0157.4IN1RF-LBT

    TX Module RadioMaster Micro/Nano 4in1 LBT

    TX Module RadioMaster Micro/Nano 4in1 LBT

    Brand: RadioMaster

    €73,92
    €73,92 €73,92
    -0% View Product
    Taxes included.
    Upon request
    We need to check the product availability with our supplier. Please contact us for details.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion
    Micro/Nano 4in1 module

The RadioMaster 4IN1 external module is a multi-protocol module that integrates CC2500, NRF24L01, A7105 and CYRF6936 RF chips. The RM 4IN1 module, designed for OpenTX and EdgeTX systems, allows the radio to connect to most common protocols on the market. Compatible with JR and Nano modules

Function:
- Output power up to 20 dBm
- Compatible with more than 70 RF protocols
- Wireless trainer function
- For Zorro, TX16S MKII, TX12 MKII and more

Specifications:
Item: RM 4IN1 Module
Region: LBT (4in1 LBT (Europe) version is limited to LBT compliant FrSKY X/X2 LBT, HoTT LBT and DSMX protocols)
Operating voltage: 4.5-8.4V
Operating frequency: 2.4G ISM band (2400 MHz - 2483 MHz)
RF Chipsets: CC2500, NRF24L01, A7105 and CYRF6936
Operating current: =100mA
RF gain: +20dBm
Weight: 30g (without antenna)
Dimensions: 73x42x22mm (without antenna)
