GEP-CT30
GEP-CT30 frame specially developed by the GEPRC team for film enthusiasts.
As a film FPV frame, the new GEP-CT30 frame series uses a high-precision 7075-T aviation aluminum alloy bracket to accompany the FPV camera. The newly polished gimbal damping module can easily solve the problems of high frequency vibration and jello. It can be mounted on multiple action cameras, which has a stable and clear image, and is easy to shoot with. The GEP-CT30 frame supports the installation of common AIO flight controllers with 25.5mm * 25.5mm mounting holes, and is compatible with various VTX mounting holes on the market, such as 20mm * 20mm/25.5mm * 25.5mm. With 12mm*12mm motor mounting holes, can be installed with larger 15-18-20 series motors with strong power with 3 inch propeller. Ultralight fuselage weight for safer flying.
It adopts high-strength one-piece injection-molded propeller cover and high-tough and impact-resistant PC injection material. A Cob ring light strip is embedded in the propeller cover, and the lighting effect is carefully tuned. Light strip kits are optional for flexible options. 7075-T aviation aluminum post, fine polished frame, only 6 screws need to be removed to separate the top plate of the aircraft and the propeller cover. Easily handle the urgent need to replace accessories, restore status at any time.
Specifications
Brand: GEPRC
Model: GEP-CT30
Engine to engine: 127mm
Insulation board: 2.0 mm
Main plate: 3.0mm
Bottom plate: 1.5 mm
FC mounting hole: 25.5mm x 25.5mm
VTX mounting hole: 20mm x 20mm / 25.5 x 25.5
Motor mounting hole: 12mm x 12mm
FPV camera pitch: 19mm
Suitable propeller size: 3 inch propeller
Weight: 103.2g (including propeller cover, 3D printed parts, Naked GP8 camera base mount, antenna tube)
