Pilotix Spider6 Advanced The Pilotix Spider6 Advanced is a 10-inch film drone with Caddx Ratel PRO analog camera, 5.8G 3W VTX and Rush Cherry II antenna. Pilotix Spider6 Advanced payload capacity is up to 5.0kg payload with 3x 6S batteries up to 8000mAh. This drone contains all the necessary components for stable and high-quality performance, ensuring a hassle-free flying experience.
Specifications:
Model: Pilotix Spider6 Advanced
Frame: Spider6 V2
Dimensions: 603x541x88mm
Weight: 2150g
Wheelbase: 556mm
Arm tube diameter: 25mm
Bottom/top plate thickness: 2mm
Flight controller (FC): Partizan H743 BMI270 gyro
Firmware: Betaflight/INAV/Ardupilot
ESC: Partizan BLS 60A 4in1
VTX: 5.8G 3W
VTX antenna: 5.8G RP-SMA RHCP 160mm
Motor: Partizan 3214 800kv (6S)
Propeller: GEMFAN 1050-3
Camera: Caddx Ratel 2 Night version
Gimbal system: 9g servo gimbal
Receiver: ELRS 915Mhz Diversity RX
GPS: BZ251 GEN10 GPS with compass
Recommended battery: 6S 8000Mah Lipo x 3
Flight time with 8000mah battery x 3:
- 40 minutes (without load)
- 24 minutes (with with a load of 3kg)
- 15 minutes (with a load of 5kg)
Maximum speed: 150km/h
Maximum flight altitude (MSL): 7000m
Maximum climb speed: 15m/s
Stable working temperature range: -20°C to 50°C
Load capacity: up to 5000g
Package contents:
1x Pilotix Spider6 Advanced
