FPV Drone iFlight Nazgul DC5 ECO HD O3 6S BNF ELRS 868/915MHz +GPS

FPV drone iFlight Nazgul DC5 ECO HD O3 6S BNF ELRS 868/915MHz

The Nazgul DC5 ECO is a 5-inch freestyle drone equipped with the latest DJI O3 digital HD system. Its unique design ensures that no propellers are visible, allowing direct use of video from the O3 air unit. With the ATF435 control unit and the BLITZ E55S 2-6S 55A ESC controller, it provides unmatched performance and reliability. The carbon fiber frame with aluminum camera mount is lightweight yet durable, and the included GoPro mount offers versatility in capturing your epic freestyle flights.

Properties

• Lightweight and durable: Carbon fiber and aluminum construction provides a strong yet lightweight structure for camera equipment. Ensures clear video without propeller obstructions.
• Anti-Spark Filter: Contains a protection circuit that prevents sparking and prolongs the life of XT60 connectors, protecting electronics from voltage or current spikes.
• Enhanced user experience and maintenance: Includes a built-in buzzer and receiver holder for easy maintenance and receiver adjustments.
• Room for customization: Offers 20x20 and 30.5x30.5 mounting holes for compatibility with popular flight kits and VTX systems, allowing for personalized setup and seamless integration.
• DJI O3 HD Air Unit low-latency digital transmission: Up to 10 km video transmission range. The HD version allows the installation of ND filters, giving more control over the camera's exposure settings.
• Stabilized video in 4K with an ultra-wide angle of 155°.

Specifications

• Product name: Nazgul DC5 ECO 6S O3 HD
• Geometry: DC (DeadCat)
• Control unit: BLITZ ATF435
• ESC: BLITZ E55S 55A 4-IN-1
• Video transmission: DJI O3 Air Unit
• Receiver option: ELRS 868/915MHz
• Frame: Wheelbase 240 mm
• Motor: XING-E Pro 2207 1800KV Motors
• Propellers: Nazgul F5 Propellers
• Weight: 437g (without battery)
• Dimensions (L×W×H): 193×144×34 mm
• Maximum speed: 190 km/h (manual mode)
• Maximum take-off height: 7000 m
• Maximum flight time in place: About 7.5 minutes (no load with 6S 1400mAh)
• Wind Resistance: Level 7
• Operating Temperature Range: -10° to 40° C (14° to 104° F)
• Antennas: Dual antenna
• GNSS: GPS+SBAS+Galileo+QZSS+Glonass

Video transmission

• Product name: DJI O3 Air Unit
• Communication Bandwidth: Max 40 MHz
• FOV (Single Screen): 155°
• Communication frequency: 2.400-2.4835 GHz (RX only) / 5.725-5.850 GHz (RX and TX)
• End-to-End Latency
  • With DJI FPV Goggles V2:
    • 810p/120fps video transmission quality: Latency lower than 28ms.
    • 810p/60fps video transmission quality: Latency less than 40ms.
  • With DJI Goggles 2:
    • 1080p/100fps video transmission quality: Latency up to 30ms.
    • 1080p/60fps video transmission quality: Latency up to 40ms.
• Maximum video bitrate: 50 Mbps
• Maximum video transmission range: 10 km (FCC), 2 km (CE), 6 km (SRRC)
• Operating Temperature Range: -10º to 40º C (14° to 104° F)
• Input voltage: 7.4-26.4 V
• Audio transmission: Not available

Package Contents

• 1 x Nazgul DC5 ECO 6S O3 HD BNF ELRS 868/915MHz
• 2 x Antennas
• 2 x Battery Pads
• 2 x Propellers (pairs)
