Crocodile5 Baby LR HD TBS NanoRX
The best design and high performance. It is a brand new 5 inch long range FPV. There are three versions: DJI Air Unit, Vista Nebula Nano and Analog 5.8G 600mW.
Crocodile5 Baby LR is a lightweight long-range FPV that can swim smoothly for long periods or Freestyle. High efficiency power system: Latest GEP 2004 2550kV motor + Gemfan 5130 propeller. Combined with Super GEP-F722-35A AIO FC and DJI HD system. Real-time 1080p 60fps video recording. If equipped with GEPRC VTC6 18650 4S1P 3000mAh batteries, the flight time can easily reach 27 minutes. 25 minutes of flight time is normally available with the GP Lite camera.
Crocodile5 Baby LR has a 3D Print holder for the GPS module. When signal loss or VTX is out of control Can trigger rescue beta flight mode: FPV flies back to approximate base position in case of emergency. Rescue mode will not automatically land. Crocodile Baby integrates GEPRC Finder. If the FPV is lost and the battery is disconnected, the GEPRC Finder buzzer will beep continuously.
Specifications:
Brand: GEPRC
Model: Crocodile5 Baby LR HD
Frame: GEP-CB5
Engine to engine: 227mm
Top plate thickness: 2.0 mm
Bottom plate thickness: 2.0 mm
Arm plate thickness: 4.0 mm
Flight control system: GEP-F722-35A AI
MCU: STM32F722
Gyroscope: 6-axis
OSD: BetaFlight OSD with AT7456E chip
Target firmware: GEPRCF722 AIO
Power: 4S LiPo/Lion
VTX: DJI Air Unit Module
Camera: Caddx Air Unit
Props: Gemfan 5130
Antenna: DJI 5.8g MMCX LHCP
Engines: GR2004 2550KV
GPS: BN-220
Weight: 252.29g
Receiver: TBS Nano RX
Recommended motors and batteries:
Engines: GR2004 2550KV
Battery: Lipo 4S 650mAh – 1300mAh or Lion 4S 3000mAh
