ESC Hobbywing SKYWALKER 80A V2

Name: ESC Hobbywing SKYWALKER 80A V2
Brand: Baltic Drones
SKU: 6100
Price: 38.60 EUR
Availability: InStock

ESC Hobbywing SKYWALKER 80A V2

Brand: Hobbywing

€38,60

~~€38,60~~ €38,60

-0% View Product

Taxes included.

In stock

Quantity

Detailed information

View full details

Description
Related Files
Discussion

ESC Hobbywing SKYWALKER 80A V2

Hobbywing Skywalker 80A V2 80 AMP AC. This high performance electronic speed controller has been specially designed for aerospace applications to maximize their potential performance. It is equipped with a high-performance bit microprocessor with a working frequency of up to 96 MHz, DEO (Driving Efficiency Optimization) technology, which significantly improves throttle response and steering efficiency, and reduces ESC temperature. This Skywalker ESC is also equipped with normal and reverse braking modes, which can effectively shorten the landing distance of the aircraft, and the search mode can help users find the aircraft according to the sound signal after the aircraft falls into a difficult environment. Get a Skywalker ESC and experience high performance and efficiency with many protection features to keep your electronics safe and ready to get your planes in the air!

Features:

- High -performance bit microprocessor (with a working frequency of up to 96 MHz)
- DEO technology (Driving Efficiency Optimization), which significantly improves driving efficiency with gas response and reduces ESC.
- Separate programming cable to connect ESC to LED (programming box sold separately), allowing users to program ESC anytime, anywhere.
- Normal and reverse braking modes, which can effectively shorten the landing distance of the aircraft.
- The search mode can help users to find the aircraft according to the sound signal after the aircraft falls in a difficult environment.
- Several protection functions, such as start-up, ESC thermal protection, capacitor thermal protection, overcurrent, overload, abnormal input voltage and gas loss signal, will effectively extend the life of the ESC.

Specifications:

- Model: 80A V2
- Input voltage: 3-6S
- BEC output: 5V @ 7A (switching mode)
- Continuous current: 80A
- Peak current: 100A
- Dimensions: 85x36x9mm (LxWxH)
- Weight: 79 g
- Supply wire: 12AWGmm
- Output wire: 14AWGmm
- Output connectors: 4.0mm (female)

The package contains:

- 1× ESC Hobbywing SKYWALKER 80A V2
