    Code: GP104683

    AIO FC GEPRC GEP-F411-35A

    AIO FC GEPRC GEP-F411-35A

    Brand: GEPRC

    €66,36
    €66,36 €66,36
    -0% View Product
    Upon request
    We need to check the product availability with our supplier. Please contact us for details.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion
    GEP-F411-35A AIO

The GEP-F4-35A is an upgraded version of the GEP-F4-20A designed to handle 35A continuous current (40A surge) and fully supports 2-6S LiPo batteries. It is compatible with a variety of motors and propellers, making it versatile for a variety of drone configurations. The AIO board offers OSD parameter settings, is 8.8g light and has 25.5mm * 25.5mm mounting holes suitable for most frames.

Specifications:

Model: GEP-F411-35A AIO
MCU: STM32F411
IMU: BMI270/Accelerometer (SPI)
Target: GEPRC_F411_AIO
OSD: Betaflight OSD with AT7456E chip
UART ports: T1 R1 / T2 R2
Beep: YES
LED: YES
USB connector: micro USB
ESC MCU: 8BB21F16G
Integrated LC filter
Continuous current: 35A
Merge current: 40A (10s)
Input voltage: 2-6S (LiPo battery)
ESC protocol: Dshot300/600, Oneshot, Multishot
Blackbox: 16 Mb
ESC Target: G_H_30 BLS
Plate size: 32 x 32 mm
Mounting holes: 25.5 x 25.5 mm
Weight: 8.8g
