VTX Pilotix R2500 SE (5.8G 2.5W) The VTX Pilotix R2500 SE is a high performance video transmitter designed for FPV racing and long distance flights. It works on 5.8G with an output power of 2.5W and provides strong and stable video transmission even in demanding environments. Thanks to its compact size and durable construction, it is suitable for a wide range of drones and offers reliable performance for professional pilots. Function: - Power self-test function. - Frequency lock function, no interference when power on. - 30.5x30.5 and 20x20 mounting holes simultaneously to improve compatibility. - Adjustable power output to 2.5W, enabling smooth switching in different environments. Specifications: Brand: Pilotix Model: R2500 SE Output power: 0-25-400-800-1500-2500mW Input voltage: 6-36V Parameter adjustment method: Button/OSD Workflow: - less than or equal to 450 mA @ 12 V, 800 mW - less than or equal to 850 mA @ 12 V, 2500 mW Number of channels: 48CH (A.B.E.R.F.L ) Antenna interface: MMCX Mounting hole: 30.5x30.5mm - 20x20mm Video format: NTSC/PAL auto Weight: 11 g (without antenna and power cable) Dimensions: 38 x 36.5 x 7.2 mm The package includes: 1x VTX Pilotix R2500 SE (5.8G 2.5W)
