Code: SKU:1H70031
TX Module Happymodel ES900TX Max 2W 915/868MHz
TX Module Happymodel ES900TX Max 2W 915/868MHz
Brand: HappyModel
Regular price
€39,00
Regular price
€39,00
Sale price
€39,00
Unit price
/
per
In stock
We have the goods in stock. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
Couldn't load pickup availability
Payment methods
- Description
- Related Files
- Discussion
TX module Happymodel ES900TX Max 2W 915/868MHz Happymodel ES900TX Max 2W is a powerful and compact device for wireless control, ideal for drones and other radio controlled models. With reliable ESP32 and ESP8285 microcontrollers and an output power of up to 33 dBm (2W), it ensures a stable connection and long-range operation. VCC input (5-13V) and firmware update via Wi-Fi make it easy to use. Other features include RGB LEDs and a cooling fan. Like its less powerful predecessor, the Happymodel ES900TX Max 2W has the JR module's compact size and lightweight construction, but the increased power gives it an edge. Function: - Increased output power up to 33 dBm (2W) - Support for open-source ExpressLRS with the possibility of firmware update via Wi-Fi - Compatibility with OpenTX based radios - Standard JR module format - Active cooling with built-in fan Specifications: Frequency option: 915/868 MHz Maximum output power: >33 dBm (2W) MCU: ESP32 + ESP8285 VCC input: 5-13V, external battery recommended. Target firmware: Happymodel_ES900_MAX (available in ExpressLRS v3.4) Firmware update: Wi-Fi External power supply: XT30 (ready to use) RGB LED: Yes Cooling fan: Yes Antenna connector: SMA Size: 72 x 48.5 x 32 mm (without antenna) Weight: 60 g The package includes: 1 x Happymodel ExpressLRS ES900TX Max 2W module 1 x T-shaped antenna
