    GEPRC Fettec G4 Alpha GF50A stack

Co-branded GEPRC Fettec G4 Alpha GF50A by GEPRC and FETTEC. The FC features a G473 main controller, built-in FETTEC Alpha firmware and high-speed S2M or Dshot2400 protocol with GF50A ESC to achieve exceptional stability and lightning-fast response. In addition, FETTEC's powerful closed-source firmware and feature-rich software will elevate your FPV flight experience to a new level.

Function:

- The flight controller uses FETTEC Alpah firmware, the ESC uses FETTEC firmware and supports high-speed protocols such as S2M and Dshot2400.
- All flight control function interfaces support SH1.0 cable connection, making it easy to assemble without soldering wires.
- Two-in-one high-definition analog socket that supports DJI digital image transmission and analog image transmission.
- FC features high robustness to handle challenging situations such as bent propellers caused by a crash, in harsh flight conditions.

Specifications:

Model: GEPRC Fettec G4 Alpha
MCU: STM32G473CEU6
IMU: llM 42602
Firmware: FETTEC ALPHA
OSD: FETTEC OSD
External buzzer: YES
External LED: YES
USB interface: TYPE-C
BEC Output: 9V@2A MAX 2.5A 5V@2A MAX 2.5A
Weight: 6.6g

Model: GEPRC Fettec GF50A 4IN1 DShot2400 ESC
MCU: STM32G071
Continuous current: 50A
Peak current: 55A
Input: 2-6S (LIPO battery)
Protocol: S2M+OW, S2M, Dshot300-2400
Galvanometer: YES
Firmware: FETTEC
Plate size: 32 x 32 mm
Installation hole location: 30.5mm x 30.5mm M4
Weight: 13g

The package includes:
1 x GEPRC Fettec GF50A 4V1 DShot2400 ESC
1 x GEPRC Fettec G4 Alpha FC
2 x SH1.0-4Pin 100mm silicone wire
1 x SH1.0-6P to SH1.0-7Pin silicone cable 60mm
1 x SH1.0 8Pin 30mm Silicone Cable
1 x Silicone cable SH1.0 7pin to 6pin 80MM
1 x XT60 power cable 110MM
1x capacitor 35V 1000uf
4 x M3*24 hexagon socket head screw
4 x M3 transparent nylon nut
10 x M3*8 damping balls
1 x Product manual
