    Motor iFlight XING 5215 X-Class 330KV

    Motor iFlight XING 5215 X-Class 330KV

    Brand: iFlight

    €102,10
    €102,10 €102,10
    -0% View Product
    Upon request
    We need to check the product availability with our supplier. Please contact us for details.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion
    XING 5215 Class X 330KV Motor

The XING 5215 motor is designed for large X-class drones, such as 11-15 inch quadcopters. Equipped with Japanese NSK bearings and N52H arc magnets, the motor provides incredible thrust, high response and extremely smooth flight characteristics.

Specifications:
Model: XING 5215 Motor
KV: 330KV
Weight (including wire): 356.4g
Size: φ60.8*40mm
Interphase resistance: 51mΩ
Peak current: 76.3A
Maximum wattage: 2441.6W
Shaft diameter: 4 mm
Stator diameter: 52.8 mm
Stator length: 15 mm
Configuration: 12N14P
Mounting holes: 30*30 φ4mm

The package includes:
1 x 5215 motor with screw pack
