    Motor iFlight XING 0803 17000KV

    Motor iFlight XING 0803 17000KV

    Brand: iFlight

    €13,00
    €13,00 €13,00
    -0% View Product
    Upon request
    We need to check the product availability with our supplier. Please contact us for details.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion
    XING 0803 FPV 17000KV motor

Specifications:
Model: XING NANO 0803
KV: 17000KV
Input voltage: 1S Lipo
Configuration: 9N12P
Stator diameter: 8mm
Shaft: 1 mm
Size: 10.9*9mm
Weight: 2.1g (with 30mm plug)
KV: 1700 KV
Weight (including wire): 2.1 g
Size: φ10.9*9mm
Interphase resistance: 58mΩ
Input voltage: 1S
Peak current: 4.11A
Maximum wattage: 16.4W
Mounting holes: 6*6 φ1.4mm
Rotor specifications: Unibell
Length of protruding shaft: 5.5 mm
Magnet: N52H Curved
Configuration: 12N14P
Bearing type: NSK
Winding: Single-core copper winding

The package includes:
1X XING NANO 0803 Brushless Motor
1X set of engine bolts
