XING 0803 FPV 17000KV motor Specifications: Model: XING NANO 0803 KV: 17000KV Input voltage: 1S Lipo Configuration: 9N12P Stator diameter: 8mm Shaft: 1 mm Size: 10.9*9mm Weight: 2.1g (with 30mm plug) KV: 1700 KV Weight (including wire): 2.1 g Size: φ10.9*9mm Interphase resistance: 58mΩ Input voltage: 1S Peak current: 4.11A Maximum wattage: 16.4W Mounting holes: 6*6 φ1.4mm Rotor specifications: Unibell Length of protruding shaft: 5.5 mm Magnet: N52H Curved Configuration: 12N14P Bearing type: NSK Winding: Single-core copper winding The package includes: 1X XING NANO 0803 Brushless Motor 1X set of engine bolts
