Code: SKU:GP106452
Motor GEPRC SPEEDX2 1505 4300KV
Motor GEPRC SPEEDX2 1505 4300KV
Brand: GEPRC
Regular price
€14,15
Regular price
€14,15
Sale price
€14,15
Unit price
/
per
In stock
We have the goods in stock. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
Couldn't load pickup availability
Payment methods
- Description
- Related Files
- Discussion
SPEEDX2 1505 4300KV motor
Description: The motor is compatible with 2.5-3.5 inch propellers. Thanks to high-precision and durable bearings, the motor has a longer service life.
Features:
- The combination of matte black and red enhances the look.
- Using high precision, durable bearings.
- Light design, high power density.
- Suitable for 2.5 to 3.5 inch lightweight drones.
Specifications:
- Model: SPEEDX2 1505 4300KV motor
- Maximum power: 340.9W
- Peak current: 21.56A/3s
- Resistance between phases: 97mΩ
- Magnet: N52H
- Bearing type: NSK/NMB
- Configuration: 12N/14P
- Dimension: φ19.5mm x 13.9mm
- Shaft diameter: φ1.5mm
- Length of protruding shaft: 4 mm
- Mounting holes: 9 mm x 9 mm (M2)
- Wire: 160mm/26AWG
- ESC: 20A-30A
- Input voltage: 16.8V (4S LiPo)
- Winding: Single-strand copper winding
- Weight: 12.7g (including wire)
- Suitable for: 2.5 to 3.5 inch lightweight models
Contains:
- 1 x SPEEDX2 1505 4300KV motor
- 6 x M2*5mm screw
- 6 x M2*7mm screw
