Code: SKU:GP101096
Motor GEPRC GEP-GR1106 (4500KV)
Motor GEPRC GEP-GR1106 (4500KV)
Brand: GEPRC
Regular price
€13,26
Regular price
€13,26
Sale price
€13,26
Unit price
/
per
Upon request
We need to check the product availability with our supplier. Please contact us for details.
Couldn't load pickup availability
Payment methods
- Description
- Related Files
- Discussion
GEP-GR1106 (4500 KV) The GEP-GR1106 motor is a compact and versatile variant with different KV ratings, making it suitable for a range of applications, including indoor use: 4500KV, 6000KV and 7500KV, each tailored for specific purposes: - 4500KV is recommended for 2-3 inch propellers and 3-4S batteries. - 6000KV is suitable for 2-2.5 inch propellers and 2-3S batteries. - 7500KV is for 1.9-2.5 inch propellers and 2S batteries. High-precision CNC machining ensures the accuracy and strength of the motor. The use of N50SH magnetic material ensures torque and resistance to high temperatures. The motor can develop a maximum pulling force of over 340g+. Japanese NSK bearings guarantee smooth engine operation. Specifications: KV options: 4500KV Configuration: 9N12P Stator diameter: 11mm Stator length: 6 mm Shaft diameter: 1.5 mm Motor dimensions (diameter x length): 14.2 mm x 14 mm No load current (A): ≤0.6A@7.4V Number of cells (LiPo): 3-4S Maximum continuous power: 153W Internal resistance: 266mΩ Maximum current (180S): 9.59A Maximum effective current: 3.8 Rotor: Arc magnets N50SH Bearings: NSK Base case: Al6061 Wire AWG: 28AWG Weight: 7.1g
