    Code: GP107230

    Motor GEPRC EM3215 750KV

    Motor GEPRC EM3215 750KV

    Brand: GEPRC

    €28,31
    €28,31 €28,31
    -0% View Product
    In stock
    We have the goods in stock. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion

    GEPRC EM3215 750KV Motor

    Features:

    • New series of EM motors, designed for long range FPV
    • High quality M5 steel shaft
    • High torque magnetic circuit design
    • 19mm x 19mm base

    Specifications:

    • EM3215 750KV
    • Model: EM3215 750KV motor
    • KV: 750KV
    • Maximum power: 1450W
    • Peak current: 61A
    • Resistance between phases: 43mΩ
    • Propeller: 10 inch propeller
    • Magnet: N52H
    • Bearing type: NMB
    • Configuration: 12N14P
    • Dimension: φ38.6mm x 30.7mm
    • Shaft diameter: φ5 mm
    • Length of protruding shaft: 17.2 mm
    • Size of mounting holes: 19 mm x 19 mm
    • Wire: 300mm/18AWG
    • ESC: 60A-80A
    • Input voltage: 25.2V (6S LiPo)
    • Winding: Multi-strand copper winding
    • Screws included: Ball head M3*8 (4 pieces) / M5 nut (1 piece)
    • Weight (including wire): 122g
    • Compatible models: 10 inch long range FPV

    Contains:

    • 1 x EM3215 motor
    • 4 x M3*8 ball head screws
