The
VL53L1X is a top-of-the-line Time-of-Flight (ToF) laser ranging sensor that expands the ST FlightSense™ product line. It is the fastest miniature ToF sensor on the market with accurate measurement up to 4 m and a fast measurement frequency of up to 50 Hz.
Features:
- Fully integrated miniature module
- Transmitter: 940 nm invisible laser (Class 1)
- SPAD (single photon avalanche diode) receiving array with integrated lens
- Low power microcontroller with sophisticated digital firmware
- Pin-compatible with VL53L0X FlightSense™ Distance Sensor
- Fast and accurate measurement over long distances
- Distance measurement up to 400 cm
- Measuring frequency up to 50 Hz
- Typical full field of view (FoV): 27°
- Programmable size of the region of interest (ROI) on the receiving field, allowing to reduce the field of view of the sensor
- Programmable ROI position on receiving array, providing multi-zone control from host device
- Easy integration
- One-component reflow module
- Can be hidden behind various cover materials
- Driver software and code examples for instant measurement
- Single power supply (2v8)
- I²C interface (up to 400 kHz)
- Disable and interrupt pin
Specifications:
- Working voltage: 3.3-5V
- Communication interface: I2C
- Dimensions: 25x10.7x3.2 mm
- Weight: 2.4g
