    GPS Module Foxeer M10Q 180 5883 Compass

    GPS Module Foxeer M10Q 180 5883 Compass

    Brand: Foxeer

    €25,23
    €24,30 €25,23
    --4% View Product
    Taxes included.
    Upon request
    We need to check the product availability with our supplier. Please contact us for details.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion
    Compass Foxeer M10Q 180 GPS 5883

Specifications:
Chip: M10 (10th generation chip)
Frequency: GPS L1GLONASS L1BDS B1GALILEO ESBAS L1QZSS L1
Input voltage: 5V
Antenna: Ceramic antenna
Channel: 72
Battery: Bilid-in
Compass: QMC5883
Compass Orientation: Plug pointing to direction of flight and antenna obviously up, BF: CW 180° Flip
Baud rate: 115,200 bps
Protocol: Dual NMEA/UBLOX
Output frequency: 1Hz-10Hz, default 10Hz
Speed ​​accuracy: 0.05 m/s
Horizontal positioning accuracy: 2D ACC1.5m (outdoor)
Receiver sensitivity: Trace -166dBm; Capture -160dBm
Dynamic characteristics: Altitude 50000m; Speed ​​500m/s; 4G acceleration
Operating temperature: -40C-+85C
Storage temperature: -40C-+105C
Weight: 7.5g
Size: 18x18x8 mm

The package includes:
1x Foxeer M10Q 180 GPS 5883 compass
