    Frame GEPRC GEP-ST35 for SMART35 Drone

    Frame GEPRC GEP-ST35 for SMART35 Drone

    Brand: GEPRC

    €43,35
    €43,35 €43,35
    -0% View Product
    Upon request
    We need to check the product availability with our supplier. Please contact us for details.
    Detailed information
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    • Related Files
    • Discussion
    GEP-ST35

The GEP-ST35 is a 3.5 inch freestyle frame. Contains multiple mounting holes for installing various FC and VTX options. Accommodates motors with bore sizes from 8mm to 13mm and is compatible with Naked GP8 and Insta 360 Go2 cameras when using the GP camera mount. The frame is constructed with 4mm arms and can also be equipped with 2mm reinforced arms, ensuring ultra high strength.

Specifications:

Brand Name: GEPRC
Model: GEP-ST35
Wheelbase: 155 mm
Top plate: 2.0mm
Bottom plate: 4.0mm
Shoulder plate: 4.0 mm
Reinforced shoulder: 2.5 mm
FC mounting holes: 26.5x26.5mm / 20x20mm
VTX mounting holes: 20x20mm
Motor mounting holes: 9x9mm / 12x12mm
Dimensions: 142 x 118 x 36 mm
Weight: 47.9g (with 3D printing and reinforced arm)
