FPV Kit Pilotix Rocky20 LF ELRS 868/915Mhz Diversity
The Pilotix Rocky20 LF DIY Kit is a high-performance, long-range drone kit designed for experienced pilots looking for exceptional payload and extended flight capabilities. With a robust 980mm wheelbase and an impressive payload of up to 5kg, this kit offers reliable performance for a variety of aviation tasks. Its powerful 5215 350kv engines paired with APC 2055 propellers ensure high efficiency and stability during flight. The kit is equipped with an ELRS 915MHz diversity receiver to increase signal reliability.
Note: Battery, VTX, camera and antenna are not part of the kit.
Specifications:
Wheelbase: Dimensions: 980 mm
Payload: 5 kg
Flight time (without load): 70 minutes
Range: 1.5 m (without load): 60 km
Speed in unloaded state: 100 km/h
Speed with full load: 80 km/h
Flight height: 6000 m
Resistance to wind speed: 15m/s
Operating temperature: -10 to 45°C
Flight controller: Pilotix H743
ESC: BLS 8S 100A 4IN1 ESC
Video transmission: None
Receiver: ELRS 868/915MHz diversity receiver
Video transmission antenna: None
Camera: None
Motor: 6210 210kv
Propeller: APC 2055 2-blade carbon fiber propeller
Recommended battery: 8S 37000mAh semi-solid battery
Package includes:
1x FPV Kit Pilotix Rocky20 LF ELRS 868/915Mhz Diversity
