FPV Drone GEPRC Cinelog25 V2 Analog ELRS2.4G

Summary

This Cinelog25 V2 update brings three versions of video transmission, the most important of which is the O3 Air Unit version. Based on the O3 Air Unit's built-in body shake stabilization requirements, the Cinelog25 V2 can achieve excellent stabilization effects by adapting the camera's damping ball.

It is redesigned to be fixed with aluminum parts and cable ties, which is convenient for battery replacement. The flight system uses the new TAKER G4 35A AIO with 1404 4500KV motors and HQ DT63mmX4 propellers for excellent flight performance. Install the propeller cover, which will effectively prevent personal injury due to flight errors. Optionally equipped with M10 GPS chip to quickly find satellites.

Cinelog25 V2 is a 2.5-inch high-speed FPV camera that integrates indoor and outdoor flying. Developed by the GEPRC team, the flying is smooth and the experience is good.

Properties

1. Added version with O3 Air Unit image transfer, ultra light weight up to 250g. Meets FAA aviation standards.
2. The O3 camera is separately attached to the shock absorber to solve the resonance problems of the IMU camera and achieve the best image stabilization effect.
3. Aluminum parts with cable clips for easy battery replacement.
4. Uses the new TAKER G4 35A AIO with better processing power. ESC overcurrent protection ensures stability and reliability.
5. Propeller protector design that effectively prevents flight errors.
6. The body is small and compact, suitable for indoor and outdoor use. Option to attach a Naked GoPro8 camera to shoot beautiful videos.

• Specifications

  • Model: Cinelog25 V2 Analog Quadcopter
  • Frame:  GEP-CL25 V2
  • Wheelbase: 114 mm
  • Gimbal plate: 2.0mm
  • Top plate: 2.5mm
  • Bottom plate: 2.0mm
  • FC system: TAKER G4 35A AIO
  • MCU: SMT32G473CEU6
  • Gyroscope: ICM 42688-P
  • OSD: Betaflight OSD with AT7456E
  • ESC: 8Bit 35A
  • VTX: GEPRC RAD 5.8G 1W (UFL)
  • Camera: Caddx Ratel2
  • Antenna: GEPRC Peano 5.8G RHCP UFL
  • Motor: SPEEDX 1404 4500KV
  • Propeller: HQProp DT63mm*4
  • GPS:M10 nano (optional)
  • Cinelog25 V2 Analog ELRS2.4 weight: 148 g ± 5 g
  • Receiver: GEPRC ELRS2.4
  • Recommended battery: LiPo 4S 660mAh-850mAh
  • Flight time: 4′00″ -6′ 00″

  Contains

  1 x Cinelog25 V2 Analog Quadcopter

  2 x HQProp DT63mm*4（2 pairs）

  1 x  M15*200mm Battery Tape

  1 x  M15*150mm Battery Tape

  2 x silicone pads under the battery

  1 x set of screws

  1 x 1.5mm L-shaped screwdriver

  1 x keychain

  1 x Bare GP8 Camera Base

  1 x T-type antenna holder
