Cinelog20 HD Wasp TBSNanoRX
Designed to mount the shock-absorbing gimbal under the independent FPV camera to reduce the image blur of the FPV glasses with good anti-shake effect. Provide mainstream versions of Link Wasp, O3 Air Unit and Walksnail HD video transmission versions, Bind-N-Fly to save you the trouble of building and tuning. The 2-inch pusher design is light and small in size, more suitable for flight shooting in complex and narrow environments. The SPEEDX2 1303.5 5500KV motor with Emax four-blade propellers allows for unhurried flight shooting. A continuation of the CineLog series anti-vibration structure, which can effectively eliminate image jello caused by the body when flying with the Naked GP Camera attached. The overall feel of the flight is soft and supple.
Specifications
Model: CineLog20 HD Wasp
Frame: GEP-CL20
Wheelbase: 100 mm
Gimbal plate: 2.0 mm
Top plate: 2.5mm
Bottom plate: 1.5 mm
FC system: GEP-F411-35A AIO
MCU: STM32F411CEU6
Gyroscope: ICM 42688-P
OSD: Betaflight OSD with AT7456E chip
ESC: 8bit 35A
Camera: Runcam Wasp
Antenna: GEPRC Peano 5.8G LHCP UFL
Motor: GR1303.5 5500KV
Propellers: EMAX Avan Micro 2×2.4×4
Weight: 133.6g
Receiver: PNP (Link built-in receiver), ELRS 2.4G, TBS Nano RX / RXSR
Recommended battery: LiHv 4S 450mah-660mah
Flight time: 4-6 min
