Please note that this version does not include the M-10 GPS. Features FPV Drone Cinebot25 S Analog TBSNanoRX
Integrated exterior design. Equipped with a reinforced carbon plate and modified material for one-piece injection molding in the lower part.
The shock-absorbing protective cover of the camera provides better stability when shooting.
Two performance versions are available: the regular with the SPEEDX2 1404 engine and the superior one with the SPEEDX2 1505 engine.
The TYPE-C and BOOT buttons on the back enable convenient parameter settings.
Optimized silicone T-shaped antenna fastener.
The Cinebot25 Lite quadcopter is equipped with a LiHV 4S 720mAh battery that weighs less than 250g.
Equipped with the new TAKER G4 45A AIO, the G4 FC has stable flight computing capabilities. The integrated 45A BL32 ESC has a strong discharge capability that supports up to 128K PWM refresh rate.
Compatibility between O3 VTX and Cabinet makes it easy to install memory cards and load footage.
The receiver's customized fixation stand simplifies the interior space.
Diversify battery selectivity with a comprehensive method of fixing aluminum components and straps.
Specifications
Model: FPV Drone Cinebot25 S Analog TBSNanoRX
Frame: GEP-CT25 Black
Wheelbase: 115 mm
FC: TAKER G4 45A AIO
MCU: STM32G473CEU6
Gyroscope: ICM 42688-P
FC firmware: TAKERG4AIO
ESC: BLHeli 32Bit 45A
Motor: SPEEDX2 1505 4300KV
Propellers: HQprop DT63mm x4
Connector: XT30
VTX: RAD mini 5.8G 1W
Camera: CADDX Ratel 2
Antenna: Peano 5.8G RHCP UFL
Receiver: TBS
Weight: Cinebot25 S Analog version PNP 170g+1g
Recommended battery: LiHV 4S 660mAh-720mAh
Flight time：5′-8’（Reference time is based on low speed flight. Actual time depends on how individuals fly. )
Includes
1 x Cinebot25 Quadcopter
1 x HQprop DT63mmx4 propeller (pack)
2 x batteries of non-slip mats
1 x 15150mm battery strap
1 x 15*180mm battery strap
1 x Naked GoPro base
1 x reserved screw pack
1 x 1.5mm L-shaped screwdriver
1 x frequency matching indicator
1 x ball damper
The package of reserved screws contains
The reserved screw pack contains:
2 x camera dampening balls
4 x M2 nuts
6 x M2*6 button head screws
4 x M2*18 button head screws
4 x M1.6*8 round head screws with collar
4 x M2*5 button head screws
4 x M1.6*10 hexagon socket head screws
2 x M2*12 button head screws
2 x M2 press nuts
2 x silicones for fixing the T-shaped antenna
