ESC SpeedyBee BL32 50A 4-in-1

Name: ESC SpeedyBee BL32 50A 4-in-1
Brand: Baltic Drones
SKU: SPEEDYBEE-BL32-50A
Price: 67.87 EUR
Availability: OutOfStock

ESC SpeedyBee BL32 50A 4-in-1

Brand: SpeedyBee

€67,87

~~€67,87~~ €67,87

-0% View Product

Taxes included.

Upon request

Quantity

Detailed information

View full details

Description
Related Files
Discussion

ESC 4in1 SpeedyBee BL32 50A

Specifications:
Product name: SpeedyBee BL32 50A 4-in-1 ESC
Firmware: SpeedyBee BL32 50A
Configurator download link: http://github.com/bitdump/BLHeli/releases
Continuous current: 50A x 4
Burst current: 55A (5 seconds)
TVS protection diode: Yes
Cooler: Yes
External capacitor: 1000uF Low ESR capacitor (included)
ESC protocol: DSHOT300/600
PWM frequency range: 16KHz-128KHz
Power: 3-6S LiPo
Output power: VBAT
Current Sensor: Support (Scale=490 Offset=0)
ESC telemetry: supported
Mounting: 30.5 x 30.5mm (hole diameter 4mm)
Dimension: 45.6 (L) x 40 (W) x 8.8 mm (H)
Weight: 19.2g with cooler





  SpeedyBee BL32 50A 4in1 ESC

Specifications:
Product name: SpeedyBee BL32 50A 4-in-1 ESC
Firmware: SpeedyBee BL32 50A
Configurator download link: http://github.com/bitdump/BLHeli/releases
Continuous current: 50A x 4
Burst current: 55A (5 seconds)
TVS protection diode: Yes
Cooler: Yes
External capacitor: 1000uF Low ESR capacitor (included)
ESC protocol: DSHOT300/600
PWM frequency range: 16KHz-128KHz
Power: 3-6S LiPo
Output power: VBAT
Current Sensor: Support (Scale=490 Offset=0)
ESC telemetry: supported
Mounting: 30.5 x 30.5mm (hole diameter 4mm)
Dimension: 45.6 (L) x 40 (W) x 8.8 mm (H)
Weight: 19.2g with cooler
