Flycolor Raptor 5 ESC - High performance, compact design
Description:
The Flycolor Raptor 5 series ESC delivers excellent performance in a lightweight and compact design, making them ideal for fixed-wing RC drones and FPV enthusiasts. With advanced technology, the Raptor 5 ensures efficient operation and smooth control, enabling stable and smooth flights.
Key features:
- ARM 32-bit Cortex MCU STM32G071: Works at up to 64 MHz, which is 25% higher performance than the previous generation.
- Wide signal compatibility: Supports common pulse width input (1-2ms) and advanced protocols such as Oneshot125, Oneshot42 and Multshot with automatic power-on detection.
- Improved layout: Improved routing and placement of components for better performance.
- Durable Cabling: High temperature resistant silicone signal cables ensure flexibility, long life and reduced crosstalk, contributing to greater stability.
Specifications:
- Model: Raptor5 G071-45A
- Battery Compatibility: 3-6S LiPo
- Continuous current: 45A
- Peak current (10 s): 25A
- BEC: Not
- Weight: 6.5g
- Dimensions: 29x14x6 mm
- Firmware: Flycolor_Raptor_5
- Applications: FPV and fixed wing RC drones
Package contents:
- 1x Flycolor Raptor 5 3-6S single ESC (variant according to selected current)
>
