Antenna TrueRC X-AIR 5.8 MK II RHCP SMA

Name: Antenna TrueRC X-AIR 5.8 MK II RHCP SMA
Brand: Baltic Drones
SKU: 0608597255645
Price: 34.74 EUR
Availability: OutOfStock

Antenna TrueRC X-AIR 5.8 MK II RHCP SMA

Prekės ženklas: TrueRC

€34,74

-% Išparduota

Mokesčiai įtraukti.

Upon request

Kiekis

Detailed information

Žiūrėti visą informaciją

Aprašymas
Susiję failai
Diskusija

TrueRC X-AIR 5.8 MK II RHCP Antenna, SMA X-AIR 5.8 Mk. II is our latest redesigned version of the X-AIR 5.8 antenna. Thanks to the use of aerospace-grade PCB material and the latest computer technology, there are no compromises in beam width, gain, or size. It takes up almost a quarter less space than the original model, has the same wide coverage and high axial ratio, making it ideal for long-distance flights without the need for antenna adjustment.

Features: - Ultra-compact, low-profile: At only ~15-16 mm thick, it is durable enough to remain mounted on goggles during transport or flight.

- Directional patch antenna with medium gain: Offers wider beam coverage (~120°) than most high-gain patch antennas, making it user-friendly for dynamic flight without the need for constant readjustment.
- Ideal for FPV goggles, including HDZero VRX4/module, HDZero goggles, Walksnail Avatar, and Fat Shark Dominator HD when using the correct SMA connector or adapters. Customized snap-on mounts or grooved connectors ensure a secure fit.

Specifications: Bandwidth: 5.1 GHz–6.7 GHz Gain: 9.5–10.5 dBic Polarization: RHCP Beam width (H and V)*: 120 degrees Beam width @-3dB(H and V)**: 68 degrees. Connector: SMA
Dimensions: 32 x 32 x 16 mm *Coverage where reception is at least equivalent to omnidirectional. **Coverage where at least 70% of maximum range is achieved. Package includes: 1x TrueRC X-AIR 5.8 MK II RHCP antenna, SMA
